VC CAMERAS
SNAP U2
- Portable full HD pocket camera compatible with all video conferencing applications
- The privacy cover (optional) prevents hackers from misusing your device or unintentional switching on of the camera
- Wide-angle lens captures all the participants in a small room or huddle room
- Built-in microphones (optional) capture every spoken word while eliminating background noise
- Full HD video
- Privacy Cover (optional)
- Built-in microphones (optional)
- USB 2.0 interface compatible with most laptops and desktops
- Compatible with all video conferencing applications
- Plug and play installation
- Work-from-anywhere
- Tele-consultation
- Online classrooms
- Huddle rooms
SNAP U2
Web Camera
- 10102823SE
Camera
- Main IC: Supports MJPEG / H.264 / H.265 compression image processing chip, supporting various ISP processing algorithms
- Image Sensor: 1/3 Inch 2.07 Megapixel sensor
- Resolution: 1080p
- Digital Zoom: NA
- Lens: f= 2.2mm
- FOV: 70°
- IR Remote: NA
Audio & Video
- Resolution: 1920 x 1080
- Video image format: YUV2 / MJPEG / H.264
- Frame Rate of video conferencing equipment for small business: 30 fps
- Image Processing: Support 3D denoising, automatic white balance, automatic gain and other image processing algorithms
- Mic: NA
- Noise Suppression: No
- Other Features of video conferencing equipment for small business: Manual Rotation
- Mounting Options: Monitor Mount
Interface
- USB: USB 2.0 interface, 1.4M cable
Physical Parameters
- Weight (g): 92g
- Dimensions(L*W*H): 75mm x 105mm x 33mm
- Power Supply: Power by USB
- Operating Temperature: -10° ~ +40°C
- Working Humidity: 10% – 90%
Applications
- Enterprise: Video Conference & Live webcast
- Medicine: Tele-medicine & Tele-consultation
- Education: Online Classes & Lecture Capture
SNAP U2
Web Camera
- 10102621SE
Camera
- Main IC: Supports MJPEG / H.264 / H.265 compression image processing chip, supporting various ISP processing algorithms
- Image Sensor: 1/3 Inch 2.07 Megapixel sensor
- Resolution: 1080p
- Digital Zoom: 2X (Optional)
- Lens: f= 2.2mm
- FOV: 70°
- IR Remote: Yes (Optional)
Audio & Video
- Resolution: 1920 x 1080
- Video image format: YUV2 / MJPEG / H.264
- Frame Rate of video conferencing equipment for small business: 30 fps
- Image Processing: Support 3D denoising, automatic white balance, automatic gain and other image processing algorithms
- Mic: Mic (Pickup upto 1.5M) Pickup upto 3M (Optional)
- Noise Suppression: Yes
- Other Features of video conferencing equipment for small business: Privacy cover 360 degree manual rotation
- Mounting Options: Monitor Mount & Tripod Mount
Interface
- USB: USB 2.0 interface, 1.4M cable.
Physical Parameters
- Weight (g): 110g
- Dimensions(L*W*H): 75mm x 105mm x 33mm
- Power Supply: Power by USB
- Operating Temperature: -10° ~ +40°C
- Working Humidity: 10% – 90%
Applications
- Enterprise: Video Conference & Live webcast
- Medicine: Tele-medicine & Tele-consultation
- Education: Online Classes & Lecture Capture
SNAP U2
Web Camera
- 10102923SE
Camera
- Main IC: Supports MJPEG / H.264 / H.265 compression image processing chip, supporting various ISP processing algorithms
- Image Sensor: 1/3 Inch 4 Megapixel sensor
- Resolution: 1080p
- Digital Zoom: 4X (Optional)
- Lens: f= 2.2mm
- FOV: 70°
- IR Remote: Yes (Optional)
Audio & Video
- Resolution: 1920 x 1080
- Video image format: YUV2 / MJPEG / H.264
- Frame Rate of video conferencing equipment for small business: 30 fps
- Image Processing: Support 3D denoising, automatic white balance, automatic gain and other image processing algorithms
- Mic: Mic (Pickup upto 1.5M)
- Noise Suppression: Yes
- Other Features of video conferencing equipment for small business: Privacy cover 360 degree manual rotation
- Mounting Options: Monitor Mount & Tripod Mount
Interface
- USB: USB 2.0 interface, 1.4M cable.
Physical Parameters
- Weight (g): 110g
- Dimensions(L*W*H): 75mm x 105mm x 33mm
- Power Supply: Power by USB
- Operating Temperature: -10° ~ +40°C
- Working Humidity: 10% – 90%
Applications
- Enterprise: Video Conference & Live webcast
- Medicine: Tele-medicine & Tele-consultation
- Education: Online Classes & Lecture Capture
SNAP U2
Web Camera
- 10102124SE
Camera
- Main IC: Supports MJPEG / H.264 / H.265 compression image processing chip, supporting various ISP processing algorithms
- Image Sensor: 1/3 Inch 5 Megapixel sensor
- Resolution: 1080p
- Lens: f= 2.2mm
- FOV: 70°
- Digital Zoom: 4X (Optional)
- IR Remote: Yes (Optional)
Audio & Video
- Resolution: 1920 x 1080
- Video image format: YUV2 / MJPEG / H.264
- Frame Rate of video conferencing equipment for small business: 30 fps
- Image Processing: Support 3D denoising, automatic white balance, automatic gain and other image processing algorithms
- Mic: Mic (Pickup upto 1.5M)
- Noise Suppression: Yes
- Other Features: 360 degree manual rotation
- Mounting Options: Monitor Mount
Interface
- USB: USB 3.0 interface, 1.4M cable
Physical Parameters
- Weight (g): 110g
- Dimensions(L*W*H): 75mm x 105mm x 33mm
- Power Supply: Power by USB
- Operating Temperature: -10° ~ +40°C
- Working Humidity: 10% – 90%
Applications
- Enterprise: Video Conference & Live webcast
- Medicine: Tele-medicine & Tele-consultation
- Education: Online Classes & Lecture Capture
